Shenzhen VIIP VIP4‑1A‑10(10247) Original EMI Filter 10A RMS 115/250VAC Metal Housing Single‑Phase AC Line Filter for EMC Compliance Test

Brand Name:	Weiaipu
Model Number:	VIP4-1A-10（10247）
MOQ:	245PCS
Price:	2.82USD
Packaging Details:	Carton
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shen Zhen

Certification:

CQC CE ROHS TUV CB REACH UL

Voltage Rating:

115/250VAC

Leakagecurrent:

≤0.3mA @115VAC/60Hz；≤0.6mA @250VAC/50Hz

Operating Frequency:

50/60Hz

Current Rating:

10A RMS Max

Productname:

Single Phase EMI Filter

Insertion Loss:

Tested Under 50Ω System, For Reference Only

Supply Ability:

3000PCS/WEEK

Highlight:

10A single-phase EMI filter

115/250VAC AC line filter

metal housing EMI filter

Product Description

Shenzhen VIIP VIP4‑1A‑10(10247) Original EMI Filter 10A RMS 115/250VAC Metal Housing Single‑Phase AC Line Filter for EMC Compliance Test

Product Overview

VIP4‑1A‑10, internal part code 10247, is a standard stock single‑phase EMI power filter manufactured by Shenzhen VIIP Electronics. This 10A‑rated AC filter applies single‑stage LC circuit topology and metal housing construction. Equipped with spade tab quick‑connect terminals and chassis mounting holes, it is friendly for mass‑production assembly. It is widely selected as standard filtering component for single‑phase AC equipment, supporting 115/250VAC 50/60Hz power grid, conforming to CE, RoHS and REACH environmental directives. Insertion loss data in datasheet is for reference only.

Highlights

Standard off‑the‑shelf EMI filter model, model code:VIP4‑1A‑10, internal PN:10247
Electrical rating:10A RMS Max, 115/250VAC, 50/60Hz single‑phase AC input
Single‑stage LC circuit with common‑mode inductor, Cx, Cy capacitors for power‑line noise suppression
Low leakage current characteristic, suitable for general commercial electronic hardware
Metal shell structure, 2×Φ4.8 mounting holes for chassis fixing
Spade tab terminal design, convenient for fast‑on connector assembly in mass production
Insulation resistance ≥100MΩ @500VDC between I/O and ground
Operating temperature:‑25℃ ~ +100℃, fit for continuous long‑run device operation

Application

- Mass‑produced switching power supply finished goods
- Batch‑produced industrial automation control devices
- Commercial test & measuring instrument manufacturing
- Volume‑produced office‑use electronic equipment
- General single‑phase AC powered devices requiring built‑in power‑line EMI filtering

Electrical Characteristics

Item	Specification
Model	VIP4‑1A‑10 (10247)
Phase	Single‑phase
Rated Voltage	115 / 250 VAC
Rated Current	10 A RMS Max.
Operating Frequency	50 / 60 Hz
Leakage Current (Line‑to‑Ground)	≤0.3 mA @115VAC,60Hz ≤0.6 mA @250VAC,50Hz
Insulation Resistance	≥100 MΩ @500VDC (Input/Output to Ground)
Circuit Topology	Single‑stage LC (Common‑mode choke + Cx, Cy capacitors)
Operating Temperature Range	‑25℃ ~ +100℃
Insertion Loss	Tested under 50Ω system (for reference only)

Electrical Schematic & Product Images

Support and Services

Product Overview: High-performance single-phase EMI filter, compliant with international standards.
Technical Support: Refer to the datasheet and installation manual for full specs, wiring diagrams, and safety guidelines.
Installation: Must be performed by qualified personnel; ensure proper grounding and secure connections per applicable electrical codes.
Maintenance: Regular inspection recommended to maintain filter efficiency and extend product lifespan.
Troubleshooting: Verify wiring, check for physical damage, and confirm operating conditions (temperature/humidity) meet specifications.
Custom Solutions: Tailored EMI filter options available, including product testing and certification support. Contact our technical team for application advice and problem resolution.

Frequently Asked Questions

What safety and environmental certifications does VIP4-1A-10 have?

VIP4-1A-10 owns CE, UL, CQC, TUV, CB, RoHS and REACH certificates.

What are voltage, current, temp & leakage current specs of VIP4‑1A‑10?

115/250VAC, 10A RMS max, 50/60Hz, operating temperature: ‑25°C ~ +100°C. Max leakage current: 0.3mA@115VAC/60Hz, 0.6mA@250VAC/50Hz.

What's its hi‑pot standard? Mount type & EMI suppression effect?

Insulation resistance ≥100MΩ @500VDC (Input/Output to Ground) for 1‑minute test. Spade tab terminals with mounting holes. Built‑in single‑stage common‑mode choke with Cx/Cy capacitors to suppress common‑mode & differential‑mode EMI noise for EMC compliance test.

Free EMC pre‑test & model selection guide? Support EMI rectification for inverters?

Free EMC pre‑test and product selection advice are available. We provide dedicated EMI rectification solutions for inverters, servo equipment.

What's the standard wire cross‑section of VIP4‑1A‑10? Can it suppress high‑frequency interference from servo drives?

Matching wiring shall satisfy 10A current‑carrying capacity. Its built‑in LC filter circuit can effectively suppress high‑frequency EMI noise generated by servo drives.

Tags:

Power Supply Input Filter 30dB

100dB Emi Filter 10A

Metal Case Emi Filter 10A
