Single Phase EMI Filter

10A 250VAC Single Phase EMI Filter VIP4‑1A‑10(10247) Low Leakage Current Chassis Mount EMC Power Noise Filter

All Category

Flat Ferrite Core

Miss. Vicky Lee

vip6@szviip.com

19925448748

19925448748

Contact Now

10A 250VAC Single Phase EMI Filter VIP4‑1A‑10(10247) Low Leakage Current Chassis Mount EMC Power Noise Filter

Brand Name:	Weiaipu
Model Number:	VIP4-1A-10（10247）
MOQ:	245PCS
Price:	2.82USD
Packaging Details:	Carton
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shen Zhen

Certification:

CQC CE ROHS TUV CB REACH UL

Voltage Rating:

115/250VAC

Leakagecurrent:

≤0.3mA @115VAC/60Hz；≤0.6mA @250VAC/50Hz

Operating Frequency:

50/60Hz

Current Rating:

10A RMS Max

Productname:

Single Phase EMI Filter

Insertion Loss:

Tested Under 50Ω System, For Reference Only

Supply Ability:

3000PCS/WEEK

Highlight:

10A single phase EMI filter

low leakage current EMI filter

chassis mount EMC power filter

Product Description

10A 250VAC Single Phase EMI Filter VIP4‑1A‑10(10247) Low Leakage Current Chassis Mount EMC Power Noise Filter

Product Overview

Model VIP4‑1A‑10(10247) is a single‑stage low‑pass EMI filter for 50/60Hz AC mains. Internal part number 10247. The topology consists of common‑mode inductor L1, X‑capacitor(Cx) and Y‑capacitors(Cy), attenuating conducted electromagnetic interference from AC input power. Rated current 10A RMS at 115/250VAC. Construction: metal enclosure, spade tab fast‑on terminals, chassis mounting holes. Insertion loss data is measured under 50Ω test system for reference only.

Highlights

‑ Single‑phase single‑stage LC EMI filter topology (CM choke + Cx, Cy)
‑ Electrical rating:10A RMS Max, 115/250VAC, 50/60Hz
‑ Line‑to‑ground leakage current: ≤0.3mA @115VAC/60Hz; ≤0.6mA @250VAC/50Hz
‑ Insulation resistance ≥100MΩ @500VDC between input/output and ground
‑ Mechanical: metal housing, spade tab terminals, chassis‑mount with 2×Φ4.8 mounting holes
‑ Operating temperature range:‑25°C ~ +100°C
‑ Insertion loss reference data under 50Ω impedance system (not guaranteed value)

Application

EMI noise suppression for single‑phase AC powered apparatus:
- Power supply units, AC‑DC power conversion modules
- Industrial control units, PLC peripheral devices
- Bench‑top test & measuring instruments
- Office automation hardware
- General‑purpose single‑phase electronic apparatus

Electrical Characteristics

Item	Specification
Model	VIP4‑1A‑10 (10247)
Phase	Single‑phase
Rated Voltage	115 / 250 VAC
Rated Current	10 A RMS Max.
Operating Frequency	50 / 60 Hz
Leakage Current (Line‑to‑Ground)	≤0.3 mA @115VAC,60Hz ≤0.6 mA @250VAC,50Hz
Insulation Resistance	≥100 MΩ @500VDC (Input/Output to Ground)
Circuit Topology	Single‑stage LC (Common‑mode choke + Cx, Cy capacitors)
Operating Temperature Range	‑25℃ ~ +100℃
Insertion Loss	Tested under 50Ω system (for reference only)

Electrical Schematic & Product Images

Support and Services

Product Overview: High-performance single-phase EMI filter, compliant with international standards.
Technical Support: Refer to the datasheet and installation manual for full specs, wiring diagrams, and safety guidelines.
Installation: Must be performed by qualified personnel; ensure proper grounding and secure connections per applicable electrical codes.
Maintenance: Regular inspection recommended to maintain filter efficiency and extend product lifespan.
Troubleshooting: Verify wiring, check for physical damage, and confirm operating conditions (temperature/humidity) meet specifications.
Custom Solutions: Tailored EMI filter options available, including product testing and certification support. Contact our technical team for application advice and problem resolution.

Frequently Asked Questions

What safety and environmental certifications does VIP4-1A-10 have?

VIP4-1A-10 owns CE, UL, CQC, TUV, CB, RoHS and REACH certificates.

What are voltage, current, temp & leakage current specs of VIP4‑1A‑10?

115/250VAC, 10A RMS max, 50/60Hz, operating temperature: ‑25°C ~ +100°C. Max leakage current: 0.3mA@115VAC/60Hz, 0.6mA@250VAC/50Hz.

What's its hi‑pot standard? Mount type & EMI suppression effect?

Insulation resistance ≥100MΩ @500VDC (Input/Output to Ground) for 1‑minute test. Spade tab terminals with mounting holes. Built‑in single‑stage common‑mode choke with Cx/Cy capacitors to suppress common‑mode & differential‑mode EMI noise for EMC compliance test.

Free EMC pre‑test & model selection guide? Support EMI rectification for inverters?

Free EMC pre‑test and product selection advice are available. We provide dedicated EMI rectification solutions for inverters, servo equipment.

What's the standard wire cross‑section of VIP4‑1A‑10? Can it suppress high‑frequency interference from servo drives?

Matching wiring shall satisfy 10A current‑carrying capacity. Its built‑in LC filter circuit can effectively suppress high‑frequency EMI noise generated by servo drives.
