VIIP VIP4‑1A‑10(10247) AC Power Line EMI Filter 10A Single‑Stage LC Circuit for Industrial Automation & Switching Power Supply Anti‑Interference

Product Overview

VIP4‑1A‑10(10247) is a cost‑effective single‑phase AC EMI power filter developed by Shenzhen VIIP Electronics. Designed for 10A RMS single‑phase mains equipment operating at 115/250VAC 50/60Hz. This metal‑cased filter adopts single‑stage LC circuit built‑in common‑mode choke together with Cx and Cy capacitors, to suppress both common‑mode and differential‑mode conducted noise on power lines. It helps end‑products pass EMC compliance tests. Spade tab terminals and chassis‑mount holes enable quick installation inside device cabinets.

Highlights

- Rated 10A RMS, 115/250VAC, 50/60Hz for general single‑phase AC equipment
- Single‑stage LC circuit suppresses common‑mode & differential‑mode conducted EMI noise
- Low leakage current: max.0.3mA@115VAC/60Hz; max.0.6mA@250VAC/50Hz
- Metal shield housing with mounting holes, convenient chassis mounting
- Spade tab terminals for fast‑on connection, simple assembly
- High insulation resistance ≥100MΩ @500VDC (I/O to ground)
- Wide operating temperature:‑25℃ ~ +100℃
- Stable performance for continuous long‑time operation

Application

Switching power supplies and AC‑DC converters
Industrial automation and control equipment
Test, measurement & laboratory instruments
Office automation devices
General consumer electronic products
Single‑phase commercial equipment requiring conducted EMI noise mitigation

Electrical Characteristics

Item	Specification
Model	VIP4‑1A‑10 (10247)
Phase	Single‑phase
Rated Voltage	115 / 250 VAC
Rated Current	10 A RMS Max.
Operating Frequency	50 / 60 Hz
Leakage Current (Line‑to‑Ground)	≤0.3 mA @115VAC,60Hz ≤0.6 mA @250VAC,50Hz
Insulation Resistance	≥100 MΩ @500VDC (Input/Output to Ground)
Circuit Topology	Single‑stage LC (Common‑mode choke + Cx, Cy capacitors)
Operating Temperature Range	‑25℃ ~ +100℃
Insertion Loss	Tested under 50Ω system (for reference only)

Electrical Schematic & Product Images

Support and Services

Product Overview: High-performance single-phase EMI filter, compliant with international standards.
Technical Support: Refer to the datasheet and installation manual for full specs, wiring diagrams, and safety guidelines.
Installation: Must be performed by qualified personnel; ensure proper grounding and secure connections per applicable electrical codes.
Maintenance: Regular inspection recommended to maintain filter efficiency and extend product lifespan.
Troubleshooting: Verify wiring, check for physical damage, and confirm operating conditions (temperature/humidity) meet specifications.
Custom Solutions: Tailored EMI filter options available, including product testing and certification support. Contact our technical team for application advice and problem resolution.

Frequently Asked Questions

What safety and environmental certifications does VIP4-1A-10 have?

VIP4-1A-10 owns CE, UL, CQC, TUV, CB, RoHS and REACH certificates.

What are voltage, current, temp & leakage current specs of VIP4‑1A‑10?

115/250VAC, 10A RMS max, 50/60Hz, operating temperature: ‑25°C ~ +100°C. Max leakage current: 0.3mA@115VAC/60Hz, 0.6mA@250VAC/50Hz.

What's its hi‑pot standard? Mount type & EMI suppression effect?

Insulation resistance ≥100MΩ @500VDC (Input/Output to Ground) for 1‑minute test. Spade tab terminals with mounting holes. Built‑in single‑stage common‑mode choke with Cx/Cy capacitors to suppress common‑mode & differential‑mode EMI noise for EMC compliance test.

Free EMC pre‑test & model selection guide? Support EMI rectification for inverters?

Free EMC pre‑test and product selection advice are available. We provide dedicated EMI rectification solutions for inverters, servo equipment.

What's the standard wire cross‑section of VIP4‑1A‑10? Can it suppress high‑frequency interference from servo drives?

Matching wiring shall satisfy 10A current‑carrying capacity. Its built‑in LC filter circuit can effectively suppress high‑frequency EMI noise generated by servo drives.
