VIIP V180215H Ni‑Zn Ferrite Core, Factory Supply High Impedance Ferrite Ring Core Sample Available RoHS REACH For Electronics Filter

Brand Name:	Weiaipu
Model Number:	V180215H
MOQ:	2040PCS
Price:	0.04USD
Packaging Details:	Carton
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ROHS REACH

Model Number:

V180215H

Material:

Ni‑Zinc Ferrite

Certification:

RoHS, REACH

Function:

EMI / RFI Suppression, Noise Absorption, EMC Anti‑interference

Application:

Consumer Electronics, Industrial Control, Communication Equipment, Medical Device, Automation Sensor

Test Frequency Range:

1‑500MHz

Product Description

VIIP V180215H Ni‑Zn Ferrite Core, Factory Supply High Impedance Ferrite Ring Core Sample Available RoHS REACH For Electronics Filter

Product Overview

V180215H is a toroidal Ni‑Zn Ferrite Core manufactured by Shenzhen VIIP Electronics Co., Ltd. Internal part number is 6080024069 . This high‑frequency Ni‑Zn Ferrite Core is specially engineered to suppress EMI and RFI noise on power cables and signal wires.

Tested across 1‑500 MHz frequency band with E4991A+16194A impedance analyzer, this Ni‑Zn Ferrite Core delivers guaranteed minimum impedance performance. Every unit undergoes strict dimensional measurement, electrical performance test and visual appearance inspection. Fully compliant with RoHS and REACH environmental requirements, this Ni‑Zn Ferrite Core fits various export‑oriented electronic end‑products.

http://mao.ecer.com/test/emcemifilter.com/sale-55777717-ni-zn-h-type-ferrite-core-v18007h-high-impedance-emc-emi-noise-suppression-for-pcba-wiring-harness-r.html

Highlights

High‑performance Ni‑Zn Ferrite Core material with initial permeability μi 650, outstanding high‑frequency noise attenuation capability for 1‑500 MHz range.
Defined electrical impedance: minimum 40Ω @25 MHz, minimum 85Ω @100 MHz, stable batch‑to‑batch consistency for mass production.
Strict visual acceptance criteria with controlled surface defect quantity, ensuring mechanical integrity during customer assembly process.
Complete impedance‑frequency characteristic curve verified by professional E4991A+16194A test system for reliable performance reference.
Compact toroidal ring‑shape design, simple cable threading, convenient for manual or automatic assembling onto harnesses.
Environment‑friendly Ni‑Zn Ferrite Core, RoHS & REACH compliant, suitable for global electronic project applications.

Electrical Characteristics

Parameter	Item	Specifications
Minimum Impedance Z1	Model	V180215H (Ni‑Zn Ferrite Core)
Minimum Impedance Z2	Minimum Impedance Z1 of Ni‑Zn Ferrite Core	40Ω @ 25 MHz
Test Instrument	Minimum Impedance Z2 of Ni‑Zn Ferrite Core	85Ω @ 100 MHz
Test Frequency Range	Test Instrument for Ni‑Zn Ferrite Core	E4991A + 16194A Impedance Analyzer
Min. Impedance @100 MHz	Test Frequency Range for Ni‑Zn Ferrite Core	1 MHz ~ 500 MHz
	Test Winding Condition for Ni‑Zn Ferrite Core	0.5 mm wire, 0.5TS, 100 mm winding length
	Typical Inductance of Ni‑Zn Ferrite Core	53.90 μH (average sample value)

Note: All typical values of this Ni‑Zn Ferrite Core are measured under standard laboratory conditions. Actual impedance will vary with winding turns, cable diameter and installation environment.

Material & Physical Properties

Item	Parameter
Material Type	High‑frequency Ni‑Zn Ferrite Core
Initial Permeability μi	650
Saturation Flux Density	260 (1600A/m)
Dimension 1	14.2 ±0.5 mm
Dimension 2	15.0 ±0.5 mm
Appearance Standard for Ni‑Zn Ferrite Core	Controlled quantity of surface defects for bare Ni‑Zn Ferrite Core
Environmental Compliance	RoHS, REACH
Document Revision	Rev4.0
Release Date	Jun.12.2025

Applications

This Ni‑Zn Ferrite Core V180215H is widely used to suppress conducted and radiated high‑frequency electromagnetic interference. Typical application scenarios for this Ni‑Zn Ferrite Core:
EMI noise filtering for high‑speed signal wiring harness by adopting this Ni‑Zn Ferrite Core in industrial control devices.
Power cable noise reduction for household appliances and commercial electronics with this Ni‑Zn Ferrite Core.
Eliminate common‑mode and differential‑mode high‑frequency disturbance for communication equipment using this Ni‑Zn Ferrite Core.
Improve signal integrity of internal wiring inside consumer electronics with this Ni‑Zn Ferrite Core.
EMC enhancement for internal cables of medical instruments by installing this Ni‑Zn Ferrite Core.
Noise suppression for sensor signal lines of automated machinery with this Ni‑Zn Ferrite Core.
Universal high‑frequency noise absorption solution for multiple electronic assemblies utilizing this Ni‑Zn Ferrite Core.

Product Images
