High Performance V180122H Ferrite Core VN02 Material EMI Noise Suppression Ferrite Core, RoHS REACH, for Cable EMC EMI Noise Attenuation of Electronic Equipment

Brand Name:	Weiaipu
Model Number:	V180122H
MOQ:	2210PCS
Price:	0.05USD
Packaging Details:	Carton
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ROHS REACH

Model Number:

V18022H

Material:

VN02 Mn‑Zn Ferrite

Certification:

RoHS, REACH

Function:

EMI / RFI Noise Suppression, Cable EMC Filtering

Application:

Power Cable, Signal Cable, Industrial Automation, Consumer Electronics, Communication Equipment

Test Frequency Range:

1‑500MHz

Highlight:

V180122H Ferrite Core VN02 Material

EMI Noise Suppression Ferrite Core

RoHS REACH Ferrite Core for Cable EMC

Product Description

High Performance V180122H Ferrite Core VN02 Material EMI Noise Suppression Ferrite Core, RoHS REACH, for Cable EMC EMI Noise Attenuation of Electronic Equipment

Product Overview

V180122H is a high‑performance snap‑on ferrite core manufactured by VIIP, serving as a EMI noise suppressor for cable EMC applications. This ferrite core is made of VN02 grade ferrite raw material, delivering reliable high‑frequency noise attenuation for power cables and signal cables.

This Mn-Zn ferrite core features precise dimension control and stable tolerance for easy cable assembly. The ferrite core can be directly clipped onto finished cables without wire cutting, supporting quick installation and mass‑volume production. Compliant with RoHS and REACH standards, this ferrite core maintains consistent filtering performance during long‑term continuous operation, helping end‑products suppress conducted RFI interference and pass EMC compliance tests.

http://mao.ecer.com/test/emcemifilter.com/sale-55777900-emi-emc-h-shape-ferrite-core-v18007h-high-freq-noise-attenuation-nizn-for-power-cable-pcb-assembly-r.html

Highlights

Stable impedance performance across 1‑500 MHz wide test frequency range
Tested by professional instrument E4991A +16194A, authentic and verifiable test data
Excellent batch‑to‑batch consistency for large‑volume electronic manufacturing
Long‑term continuous‑operation capability without obvious performance degradation
Effectively suppress conducted EMI noise on power cables and signal cables

Electrical Characteristics

Parameter	Specification	Test Condition
Minimum Impedance Z1	55 Ω Min	25 MHz
Minimum Impedance Z2	120 Ω Min	100 MHz
Test Instrument	E4991A + 16194A	Impedance‑frequency test
Test Frequency Range	1‑500 MHz	00.5×0.5TS×100L(mm) test winding
Min. Impedance @100 MHz	≥ 100 Ω

Note: This snap‑on ferrite core provides effective high‑frequency EMI & RFI noise attenuation. Impedance‑frequency curve reflects noise‑suppression performance of the ferrite core across 1‑500MHz frequency band.

Material & Physical Properties

Item	Specification
Ferrite Material Grade	VN02 Mn‑Zn ferrite core
Initial Permeability (μi)	650
Saturation Magnetic Flux Density (Bs)	260 mT @1600 A/m
Coercivity	35 A/m
Curie Temperature (Tc)	＞140 ℃
Density	4.6 g/cm³
Key Dimension A	5 ±0.3 mm
Compliance	RoHS, REACH
Appearance Standard	Defect quantity controlled per OD specification, consistent mechanical dimension tolerance

This VN02 ferrite core features high electrical resistivity and stable magnetic performance. The ferrite core keeps stable magnetic characteristics under continuous working loads, ensuring batch‑to‑batch consistency for mass production.

Applications

Medical electronic equipment: Noise suppression for low‑voltage signal cables of medical devices, this ferrite core cuts conducted interference and avoids abnormal signal fluctuation.
Automotive electronics: EMC improvement for on‑board auxiliary wiring harnesses, the ferrite core reduces electromagnetic crosstalk among vehicle electronic modules.

Product Images

Frequently Asked Questions

Can I get free samples for H-series ferrite cores?

Yes, we can provide free H-series ferrite core samples for your performance testing and product evaluation.

What is your regular order requirement for ferrite cores?

Normally mass orders need to comply with our minimum package quantity requirement.

Does the free-sample policy allow small-quantity orders below MOQ for regular purchases?

Free samples are only intended for performance verification. While your first trial order can be negotiated, formal repeat orders must follow our minimum package quantity rule.

What certificates do H-series ferrite cores have?

Our H-series ferrite cores meet RoHS and REACH regulatory requirements.

What is the typical production lead-time for mass-production ferrite core orders?

Typical production lead-time ranges from 2 to 5 weeks, subject to order volume and stock status. Exact lead-time will be confirmed prior to your formal order placement.

Can you customize impedance, physical dimensions or material for H-type ferrite cores?

Customization service is available based on your detailed technical specifications. A dedicated MOQ will apply for all customized ferrite core projects.

Could you provide EMC technical support when I apply your ferrite cores in my projects?

Sure. Our in-house engineering team provides basic EMC technical consultation to assist you with noise-suppression design and circuit debugging work.

What applications are H-series ferrite cores suitable for?

H-series Ni-Zn ferrite cores are widely used for EMI / EMC noise suppression on PCBA traces, wiring harnesses, power cables, consumer electronics, power supplies and communication-related equipment.
