V180122H Ferrite Core VN02 Grade EMI Noise Suppressor 55Ω@25MHz 120Ω@100MHz Clip‑on RFI Filter for Cable EMC Application RoHS REACH Compliant

All Category

Flat Ferrite Core

Miss. Vicky Lee

vip6@szviip.com

19925448748

19925448748

Contact Now

V180122H Ferrite Core VN02 Grade EMI Noise Suppressor 55Ω@25MHz 120Ω@100MHz Clip‑on RFI Filter for Cable EMC Application RoHS REACH Compliant

Brand Name:	Weiaipu
Model Number:	V180122H
MOQ:	2210PCS
Price:	0.05USD
Packaging Details:	Carton
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ROHS REACH

Model Number:

V18022H

Material:

VN02 Mn‑Zn Ferrite

Certification:

RoHS, REACH

Function:

EMI / RFI Noise Suppression, Cable EMC Filtering

Application:

Power Cable, Signal Cable, Industrial Automation, Consumer Electronics, Communication Equipment

Test Frequency Range:

1‑500MHz

Highlight:

Ferrite Core EMI Noise Suppressor

Clip-on RFI Filter for Cable

55Ω@25MHz 120Ω@100MHz Ferrite Core

Product Description

V180122H Ferrite Core VN02 Grade EMI Noise Suppressor 55Ω@25MHz 120Ω@100MHz Clip‑on RFI Filter for Cable EMC Application RoHS REACH Compliant

Product Overview

V180122H is a high‑performance snap‑on ferrite core manufactured by VIIP, serving as a EMI noise suppressor for cable EMC applications. This ferrite core is made of VN02 grade ferrite raw material, delivering reliable high‑frequency noise attenuation for power cables and signal cables.

This Mn-Zn ferrite core features precise dimension control and stable tolerance for easy cable assembly. The ferrite core can be directly clipped onto finished cables without wire cutting, supporting quick installation and mass‑volume production. Compliant with RoHS and REACH standards, this ferrite core maintains consistent filtering performance during long‑term continuous operation, helping end‑products suppress conducted RFI interference and pass EMC compliance tests.

http://mao.ecer.com/test/emcemifilter.com/sale-55777877-high-consistency-h-type-ni-zn-ferrite-core-v18007h-6080024033-1-500mhz-tested-emi-filter-for-cm-dm-n.html

Highlights

Made of premium VN02 grade Mn‑Zn ferrite material for reliable EMC noise suppression
Minimum impedance 55Ω at 25 MHz for effective mid‑frequency interference attenuation
Delivers minimum impedance 120Ω at 100 MHz for excellent high‑frequency noise blocking
Initial permeability μi up to 650, offering superior electromagnetic absorption capability
High saturation flux density Bs:260 mT @1600A/m, resistant against magnetic saturation

Electrical Characteristics

Parameter	Specification	Test Condition
Minimum Impedance Z1	55 Ω Min	25 MHz
Minimum Impedance Z2	120 Ω Min	100 MHz
Test Instrument	E4991A + 16194A	Impedance‑frequency test
Test Frequency Range	1‑500 MHz	00.5×0.5TS×100L(mm) test winding
Min. Impedance @100 MHz	≥ 100 Ω

Note: This snap‑on ferrite core provides effective high‑frequency EMI & RFI noise attenuation. Impedance‑frequency curve reflects noise‑suppression performance of the ferrite core across 1‑500MHz frequency band.

Material & Physical Properties

Item	Specification
Ferrite Material Grade	VN02 Mn‑Zn ferrite core
Initial Permeability (μi)	650
Saturation Magnetic Flux Density (Bs)	260 mT @1600 A/m
Coercivity	35 A/m
Curie Temperature (Tc)	＞140 ℃
Density	4.6 g/cm³
Key Dimension A	5 ±0.3 mm
Compliance	RoHS, REACH
Appearance Standard	Defect quantity controlled per OD specification, consistent mechanical dimension tolerance

This VN02 ferrite core features high electrical resistivity and stable magnetic performance. The ferrite core keeps stable magnetic characteristics under continuous working loads, ensuring batch‑to‑batch consistency for mass production.

Applications

Industrial automation: Cable EMC filtering for industrial power lines, this ferrite core suppresses high‑frequency noise and optimizes electromagnetic compatibility of control devices
Consumer electronics: EMI mitigation for signal cables, the ferrite core reduces radio‑frequency interference and secures intact signal transmission
Communication & energy equipment: Noise reduction for device internal wiring, this ferrite core helps finished units satisfy RoHS and REACH environmental requirements
Electronic device assembly: Used on power cords and signal harnesses, this ferrite core eliminates conducted interference to assist products in meeting EMC test requirements

Product Images

Frequently Asked Questions

Can I get free samples for H-series ferrite cores?

Yes, we can provide free H-series ferrite core samples for your performance testing and product evaluation.

What is your regular order requirement for ferrite cores?

Normally mass orders need to comply with our minimum package quantity requirement.

Does the free-sample policy allow small-quantity orders below MOQ for regular purchases?

Free samples are only intended for performance verification. While your first trial order can be negotiated, formal repeat orders must follow our minimum package quantity rule.

What certificates do H-series ferrite cores have?

Our H-series ferrite cores meet RoHS and REACH regulatory requirements.

What is the typical production lead-time for mass-production ferrite core orders?

Typical production lead-time ranges from 2 to 5 weeks, subject to order volume and stock status. Exact lead-time will be confirmed prior to your formal order placement.

Can you customize impedance, physical dimensions or material for H-type ferrite cores?

Customization service is available based on your detailed technical specifications. A dedicated MOQ will apply for all customized ferrite core projects.

Could you provide EMC technical support when I apply your ferrite cores in my projects?

Sure. Our in-house engineering team provides basic EMC technical consultation to assist you with noise-suppression design and circuit debugging work.

What applications are H-series ferrite cores suitable for?

H-series Ni-Zn ferrite cores are widely used for EMI / EMC noise suppression on PCBA traces, wiring harnesses, power cables, consumer electronics, power supplies and communication-related equipment.

http://mao.ecer.com/test/emcemifilter.com/sale-55777717-ni-zn-h-type-ferrite-core-v18007h-high-impedance-emc-emi-noise-suppression-for-pcba-wiring-harness-r.html
