VIP4-1A-10 (10271) 10A Single Phase EMI Power Filter 250VAC For Industrial Equipment
All Category

EMC EMI Filter

Single Phase EMI Filter

3 Phase EMI Filter

Ferrite Rings Around Cables

DC EMI Filters

AC EMI Filter

IEC EMI Filter

Military EMI Filters

Inverter EMI Filter

PCB Low Pass Filter

EMI Suppression Filter

Clip On Ferrite Core

Snap On Ferrite Choke

EMI Ferrite Core

Flat Ferrite Core
Contact Us
Miss. Vicky Lee
vip6@szviip.com
19925448748
wechat 19925448748
Contact Now
VIP4-1A-10 (10271) 10A Single Phase EMI Power Filter 250VAC For Industrial Equipment
  • Name
  • Name
  • Name
  • Name
  • Name
  • Name
  • Name

VIP4-1A-10 (10271) 10A Single Phase EMI Power Filter 250VAC For Industrial Equipment

Brand Name: Weiaipu VIIP
Model Number: VIP4-1A-10 (10271)
MOQ: 120
Price: 4.17$
Packaging Details: neutral
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Place of Origin:
china
Certification:
CB UL CQC RoHS REACH
Voltage Rating:
115/250VAC
Current Rating:
10A RMS Max
Operating Frequency:
50/60Hz
Line To Ground:
2000 VAC
Line To Line:
1450 VDC
Temperature Range:
-25°C~+100°C
Supply Ability:
30K/MONTH
Highlight:

10A single phase EMI power filter

,

EMI power filter for industrial equipment

,

250VAC EMI filter with warranty

Product Description

Product Brief Introduction

VIP4-1A-10 is a high performance single phase EMI power filter with 10A rated current for AC power line noise suppression. It supports 115VAC and 250VAC input and works under 50Hz and 60Hz power frequency. With single stage LC filtering structure it can effectively reduce common mode electromagnetic noise on power lines. It provides clean power for electronic equipment and improves system anti interference capability. It features reliable electrical safety wide working temperature range and compact structure for industrial and civil electronic applications.

VIP4-1A-10 (10271) 10A Single Phase EMI Power Filter 250VAC For Industrial Equipment

Application Scope and Usage

This 10A EMI filter is widely used in single phase electronic equipment that needs EMC improvement. Typical applications include industrial automation equipment precision measuring instruments household appliances switching power supplies communication devices and office automation equipment. It suppresses high frequency power grid interference prevents equipment malfunction and signal disorder caused by electromagnetic disturbance. It helps finished products pass international EMC certifications and avoids mutual interference among electronic devices to enhance overall system stability and safety.

VIP4-1A-10 (10271) 10A Single Phase EMI Power Filter 250VAC For Industrial Equipment

FAQ

Q1 What is the core function of an EMI power filter

A1 The core function of the EMI power filter is to remove high frequency electromagnetic noise on AC power lines. It blocks interference from power grid entering equipment and suppresses noise generated by the equipment itself. It stabilizes power quality protects sensitive electronic parts and helps products pass EMC compliance tests.

Q2 How to check if this 10A filter fits my equipment

A2 You can judge suitability based on your equipment working voltage working current and application environment. This filter works with 115VAC and 250VAC single phase power supply and the actual working current should not exceed 10A. If your power parameters match the specifications this filter can meet your noise reduction and anti interference requirements.

Q3 What will influence the filtering performance

A3 Filtering performance is mainly affected by installation method grounding condition and wiring arrangement. Installing the filter close to the equipment power inlet using short and solid ground wire and separating input wires from output wires can achieve the best noise suppression. Poor grounding or mixed input and output cables will greatly weaken filtering effect.

Q4 Is EMI filter necessary for electronic products for export

A4 Yes EMI filter is essential for most exported electronic products. Power noise and electromagnetic interference may lead to unstable operation and signal errors. Adding an EMI filter can improve product stability and help your products meet EMC standards required by overseas markets.

Q5 Does this EMI filter need regular maintenance

A5 This EMI filter adopts high quality raw materials and stable circuit design. It requires no daily maintenance. Users only need to keep the installation environment dry and clean avoid over current operation. It can maintain stable filtering performance for long term continuous operation.

Tags:
