Product Description

This high-performance EMI ferrite core is professionally engineered to suppress electromagnetic interference across diverse electronic devices and circuits. Adopting premium-grade materials and precise manufacturing techniques, this EMI choke core delivers superior noise reduction performance, effectively optimizing electromagnetic compatibility and stabilizing the operation of electronic equipment. Featuring robust structural design and consistent magnetic characteristics, it maintains reliable working performance even in complex and rigorous application environments, greatly improving circuit efficiency and operational stability.

Crafted from high-stability VN19 ferrite material, this core achieves a rated initial permeability of 1600. Such excellent magnetic permeability enables the component to rapidly absorb and dissipate high-frequency noise signals, effectively restraining stray electromagnetic interference within circuits. The VN19 material features outstanding thermal stability and electrical consistency, ensuring steady magnetic output despite frequent temperature changes and fluctuating electrical loads during long-term operation.

The core is designed with a remanence value of 360, representing stable residual magnetization capacity after external magnetic field removal. Moderate residual magnetism effectively sustains continuous noise suppression without causing magnetic saturation or signal distortion, guaranteeing pure and stable signal transmission.

With a coercivity rating of 30, this ferrite core features excellent demagnetization resistance. It can complete fast magnetization and demagnetization responses following electromagnetic field changes, ensuring efficient wide-spectrum EMI filtering and enhancing the overall operational reliability of terminal electronic products.

Equipped with a low relative temperature coefficient ranging from 1 to 3, the core possesses outstanding thermal stability. Its magnetic parameters will not drift significantly under variable temperature conditions, avoiding performance degradation in fluctuating working environments. This advantage makes it highly adaptable for automotive, industrial and consumer electronic scenarios with strict temperature requirements.

Featuring a practical sleeve structure, this ferrite EMI core supports flexible and convenient installation. It can be directly sleeved on various signal lines and power cables to block high-frequency noise transmission and prevent interference diffusion inside the system, effectively upgrading the electromagnetic compatibility of finished equipment.

To sum up, the VN19 ferrite core model V18017FS with 1600 initial permeability, 360 remanence, 30 coercivity and 1-3 temperature coefficient is a premium EMI suppression solution. With stable magnetism, strong temperature adaptability and easy assembly, it serves as an essential passive component for electronic engineers to optimize circuit performance and eliminate electromagnetic interference.

Features

• Product Type: High-performance EMI Suppression Ferrite Core
• Core Function: Effectively eliminates high-frequency electromagnetic noise and circuit interference
• Premium Material: Adopts high-stability VN19 ferrite for durable and consistent magnetic performance
• Initial Permeability: 1600 for efficient high-frequency noise absorption
• Remanence: 360 for stable residual magnetization and continuous filtering performance
• Coercivity: 30 for flexible magnetic response and anti-demagnetization capability
• Density: 5.0 for compact structure and excellent structural stability
• Versatile Application: Suitable for EMI noise elimination of various circuit boards and cable lines
• Flexible Installation: Supports sleeve-type mounting for fast assembly on different wires


Technical Parameters

Material: VN19 Initial Permeability: 1600 Remanence: 360 Coercivity: 30 Relative Temperature Coefficient: 1-3 Density: 5.0

Applications

V18017FS ferrite core is a professional EMI filtering component developed for precise electromagnetic interference suppression. Manufactured in China and fully compliant with RoHS and REACH environmental standards, it meets global industrial safety and environmental requirements. Thanks to its stable magnetic parameters and ultra-low temperature drift characteristics, this core maintains consistent filtering performance under complex working conditions.

Widely applicable in fields requiring strict electromagnetic compatibility, the product is commonly used for noise filtering of switching power supplies, communication equipment and daily consumer electronics. Its compact toroidal structure effectively saves internal space of equipment while maintaining excellent interference suppression capability. It is extensively adopted in automotive electronics, medical devices, industrial automation and other high-reliability industries to ensure stable operation of precision electronic components.

Benefiting from balanced magnetic performance and excellent mechanical toughness of VN19 material, this ferrite core adapts to various slightly harsh working environments. It is widely applied in computer motherboards, television equipment, audio systems, LED lighting circuits and other scenarios, helping terminal products pass EMC tests and improve overall product stability and user experience.

Customization Service

We provide professional customized services for all series of electromagnetic interference ferrite cores. The V18017FS ferrite core is produced in strict accordance with international RoHS and REACH standards with reliable quality and environmental safety.

We support small-batch trial orders starting from 100 pieces, with standard carton packaging to avoid damage during transportation. With a daily production capacity of 2000 pieces and a delivery cycle of 5-7 working days, we can stably support customers’ mass production and purchasing demands.

All products feature stable parameters including 5.0 density, 360 remanence, 1600 initial permeability, 1-3 temperature coefficient and 30 coercivity, ensuring standardized and reliable EMI suppression performance. We accept T/T payment terms to provide convenient and efficient purchasing service for global customers.

Updated General Ferrite Core FAQ

Q1: What frequency range is V18017FS Mn-Zn ferrite core suitable for? A1: This Mn-Zn ferrite core is optimized for low and medium frequency bands. It delivers the best EMI filtering and noise suppression effect for conventional power circuits and signal lines within medium and low frequency ranges.

Q2: Why does ferrite core impedance vary in different test environments? A2: Ferrite impedance is highly frequency-sensitive. Different test frequencies, ambient temperatures and winding turns will directly lead to different impedance test data, which belongs to normal physical characteristics.

Q3: How to improve the noise reduction effect of ferrite magnetic rings? A3: Properly increasing winding turns, optimizing winding methods, and matching the core size with wire diameter can effectively improve impedance performance, thereby achieving better high-frequency noise suppression results.

Q4: Can this ferrite core work stably in long-term high-temperature environments? A4: Yes. With a low temperature coefficient and high Curie temperature, the V18017FS core maintains stable magnetic performance under normal continuous heating conditions without obvious performance attenuation.

Q5: What is the difference between split type and integral ferrite core? A5: Integral ferrite cores feature higher structural stability and better filtering effect, while split bead cores support convenient on-site installation and disassembly, suitable for post-production noise improvement.

Q6: Does the winding direction affect the filtering performance of ferrite core? A6: Winding direction has little impact on basic filtering performance, but standardized and neat winding can reduce parasitic capacitance and avoid abnormal high-frequency performance attenuation.

Q7: Is surface insulation treatment necessary for these ferrite cores? A7: Yes. The surface insulation layer prevents wire scratching and short circuits during winding, ensuring the safety and long-term operational stability of finished choke coils.

Q8: Can ferrite cores completely eliminate all electronic noise? A8: Ferrite cores can suppress most high-frequency common-mode noise. Combined with reasonable circuit design, they can effectively help products pass standard EMC certification tests.
