Ni-Zn H-Type Ferrite Core V18007H High Impedance EMC EMI Noise Suppression for PCBA Wiring Harness RoHS REACH Compliant

All Category

Flat Ferrite Core

Miss. Vicky Lee

vip6@szviip.com

19925448748

19925448748

Contact Now

Ni-Zn H-Type Ferrite Core V18007H High Impedance EMC EMI Noise Suppression for PCBA Wiring Harness RoHS REACH Compliant

Brand Name:	Weiaipu
Model Number:	V18007H
MOQ:	3000PCS
Price:	0.02USD
Packaging Details:	Carton
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ROHS REACH

Material Grade:

Test Frequency Range:

1 MHz ~ 500 MHz

Initial Permeability μi:

20 @0.1 MHz

Highlight:

Ni-Zn ferrite core for PCBA wiring

H-Type ferrite core high impedance

EMI noise suppression ferrite core

Product Description

Ni-Zn H-Type Ferrite Core V18007H High Impedance EMC EMI Noise Suppression for PCBA Wiring Harness

Product Overview

The V18007H is an EMI suppression ferrite core manufactured by Shenzhen VIIP Electronics Co., Ltd, designed for EMC noise suppression. This high-performance component effectively suppresses high-frequency electromagnetic interference within electronic circuits and fully complies with RoHS & REACH environmental requirements.

Impedance performance is verified with 10-piece production sample test data, targeting noise attenuation across the 1-500 MHz frequency range. Its toroidal gap-free magnetic-path design provides stable broadband noise-reduction performance for cable harness and circuit-level EMC optimization.

Key Features

Delivers excellent high-frequency noise attenuation for cables and PCBA circuit traces
Effectively suppresses both common-mode and differential-mode high-frequency electromagnetic interference
Adopts high-resistivity Ni-Zn ferrite material to reduce eddy-current loss and maintain stable high-frequency magnetic performance
Noise filtering for peripheral connection lines of communication terminal equipment
H-type ferrite core, H-shape ferrite core, Ni-Zn ferrite core, NiZn ferrite ring

Electrical Characteristics

Item	Specification
Test instrument	E4991A
Test frequency range	1 MHz ~ 500 MHz
Test winding fixture	Ø0.5 _0.5TS_ 100L(mm)
Typical Impedance @25 MHz (average of 10 samples)	26.8 Ω (Min. 20 Ω spec)
Typical Impedance @100 MHz (average of 10 samples)	77.9 Ω (Min. 40 Ω spec)

Impedance-vs-frequency test curve is attached in the official approval sheet for reference.

Material Properties

Parameter	Value
Material Grade	VNO2
Initial permeability μi	20 @0.1 MHz
Relative Loss Factor	20*10⁻⁶ @0.1 MHz

Applications

EMI noise suppression for small-size signal cables, sensor wiring and internal device harness
Anti-interference treatment for consumer electronics, smart home equipment and portable instrument signal lines
High-frequency noise filtering for handheld test devices, IoT modules and wireless peripheral cables
Conducted interference reduction for small-size power adapters and low-power control boards
EMC optimization for miniature industrial sensors, security monitoring equipment harness
High-reliability cable EMI suppression for medical small-size auxiliary equipment

Product Images

Frequently Asked Questions

Can I get free samples for H-series ferrite cores?

Yes, we can provide free H-series ferrite core samples for your performance testing and product evaluation.

What is your regular order requirement for ferrite cores?

Normally mass orders need to comply with our minimum package quantity requirement.

Does the free-sample policy allow small-quantity orders below MOQ for regular purchases?

Free samples are only intended for performance verification. While your first trial order can be negotiated, formal repeat orders must follow our minimum package quantity rule.

What certificates do H-series ferrite cores have?

Our H-series ferrite cores meet RoHS and REACH regulatory requirements.

What is the typical production lead-time for mass-production ferrite core orders?

Typical production lead-time ranges from 2 to 5 weeks, subject to order volume and stock status. Exact lead-time will be confirmed prior to your formal order placement.

Can you customize impedance, physical dimensions or material for H-type ferrite cores?

Customization service is available based on your detailed technical specifications. A dedicated MOQ will apply for all customized ferrite core projects.

Could you provide EMC technical support when I apply your ferrite cores in my projects?

Sure. Our in-house engineering team provides basic EMC technical consultation to assist you with noise-suppression design and circuit debugging work.

What applications are H-series ferrite cores suitable for?

H-series Ni-Zn ferrite cores are widely used for EMI / EMC noise suppression on PCBA traces, wiring harnesses, power cables, consumer electronics, power supplies and communication-related equipment.
