Product Description:

The AC EMI Filter operates at a frequency of 50/60Hz and is a type of Power Line Filter. This filter is designed to be mounted using the Through Hole mounting type. The transfer function of this filter is AC, which means it is designed to filter out unwanted AC signals.

The AC EMI Filter is a critical component in EMC EMI Filter design. It is designed to protect electronic devices from EMI/RFI generated by other electronic devices. The filter works by using a combination of capacitors, inductors, and resistors to suppress unwanted signals. The filter is designed to provide a high level of attenuation for EMI/RFI signals, allowing electronic devices to operate correctly.

The AC EMI Filter is widely used in a range of applications, including power supplies, lighting systems, motor control systems, and more. The filter is particularly useful in applications where sensitive electronic devices are used, such as in medical equipment, telecommunications, and aerospace applications.

In summary, the AC EMI Filter is a type of EMI RFI Filter that is designed to suppress unwanted signals in AC power lines. The filter operates at a frequency of 50/60Hz and is designed to be mounted using the Through Hole mounting type. The transfer function of the filter is AC, and it is widely used in a range of applications where EMI/RFI suppression is required. The filter is a critical component in EMC EMI Filter design, and it is designed to protect electronic devices from EMI/RFI generated by other electronic devices.

Features:

• Product Name: AC EMI Filter
• Product Type: Power Line Filters
• Current Rating: 20A
• Operating Frequency: 50/60Hz
• Line To Line: 1760VDC
• Stopband Attenuation: 20~100dB
• Keywords: Inline EMI Filter, EMI EMC Filter, EMI Power Line Filter

Technical Parameters:

This Inline EMI Filter is ideal for use in Electrical Cabinet Air Filters and EMI RFI Filters.

Applications:

This EMI filter SMD is useful in a variety of applications such as industrial, military, and medical equipment. It is particularly useful in applications that require high levels of noise immunity and signal integrity.

The Weiaipu VIP4-2B-20 EMI Power Filter can be used in a variety of scenarios including power supplies, motor drives, and inverters. It can also be used in telecommunications equipment and other high-frequency applications where signal integrity is critical.

With an input impedance of 50 Ω and a line to line voltage of 1760VDC, this EMI filter is capable of handling high levels of electromagnetic interference. It is built to a high standard and is manufactured in Shenzhen, ensuring that it meets the needs of the most demanding applications.
