Product Details:
|
| Type: | AC Single Filter | Rated Voltage: | 110/250VAC |
|---|---|---|---|
| Transfer Function: | Low Pass | Application: | Electronic Equipments |
| Package Type: | Surface Mount | Certification: | CE ROHS,CE CQC |
| High Light: | CQC Certified AC EMI Filter,50HZ AC EMI Filter,250V Low Frequency Filter |
||
| Item number | VIP4-2B-20 |
| Package Type | Surface Mount |
| Nominal Center Frequency | 10KHZ-30MHZ |
| Insertion Loss | 60~90dB |
| Input Impedance | 50Ω |
| Rated Voltage | 110V/250V |
| Rated Current | 20A |
| Environmental Temperature | 40°C |
| Temperature | 25 / 085 / 21 |
| Operating Frequency | 50/60HZ |
| Line to Line | 1760VDC |
| Line to Ground | 2200VDC |
| Maximum Leakage Current | 250VAC/60HZ 0.8mA Max |
| MOQ | 5pcs |
| PORT | Shenzhen |
| Lead Time | 5~15 working days |
Features:
This is a low frequency AC filter designed for 110V/250V power electronics equipment. It features terminal block for convenient wiring connection.Features:
•110Vac/250Vac,50/60Hz input
•3A maximum rated current
•EMI noise attenuation up to 35dB from 30KHz to 10MHz
•Compact plastic case, flame retardant and RoHS compliant
•Terminal block for quick installation and wiring
•CE markedApplications:
•AC/DC power supplies
•Frequency inverters
•Electric control products
•Prevent low frequency noises generated from power electronics
•Improve the performance of sensitive circuits by filtering power source
•Meet EMC compliance standards for reliable operationThis AC power line filter suits various low voltage power electronics equipment to suppress power line EMI noises in the low frequency spectrum. It has a rated current up to 3A at 250Vac and provides high attenuation for frequencies ranging from 30KHz to 10MHz. The convenient terminal block allows easy and reliable wiring connection.
Specifications:
| Part No. | Rated Current [A] | 250VAC/50Hz @ 20C Leakage Current [mA] |
Physical Dimensions | Electrical Schematics | Terminals | Weight [g] | ||
| screw | terminal block | wires | ||||||
| VIP4-1A-01 | 1A | <0.5mA | Fig 1 | Fig 1 | - - - | - - - | 0 | 65 |
| VIP4-1A-03 | 3A | <0.5mA | Fig 1 | Fig 1 | - - - | - - - | 0 | 65 |
| VIP4-1A-06 | 6A | <0.5mA | Fig 1 | Fig 1 | - - - | - - - | 0 | 65 |
| VIP4-1A-10 | 10A | <0.5mA | Fig 2 | Fig 1 | - - - | 0 | - - - | 75 |
| VIP4-1B-06 | 6A | <1.0mA | Fig 3/Fig4 | Fig 2 | M4 | 0 | - - - | 140 |
| VIP4-1B-10 | 10A | <1.0mA | Fig 3/Fig4 | Fig 2 | M4 | 0 | - - - | 170 |
| VIP4-1B-20 | 20A | <1.0mA | Fig 3/Fig4 | Fig 2 | M4 | 0 | - - - | 170 |
| VIP4-1B-30 | 30A | <1.0mA | Fig 5 | Fig 2 | M6 | - - - | - - - | 320 |
| VIP4-1B-50 | 50A | <2.0mA | Fig 5 | Fig 2 | M6 | - - - | - - - | 600 |
| VIP4-1B-100 | 100A | <2.0mA | Fig 5 | Fig 2 | M8 | - - - | - - - | 1380 |
| VIP4-1B-150 | 150A | <2.0mA | Fig 5 | Fig 2 | M10 | - - - | - - - | 1900 |
| VIP4-1B-200 | 200A | <2.0mA | Fig 5 | Fig 2 | M10 | - - - | - - - | 1900 |
FAQ:
Q1: Do you offer customized product ?
A: Yes, we can develop a new mold at you need if you can provide us with the samples or drawings and specification.
Q2: Are you a factory?
A: Yes, we are an ISO9001 manufacturer, an integration of EMI filter R&D, production and sales since 2009.
Q3: How long is the delivery time?
A: We ensure the fast delivery. Generally, it will take 2-5 days for small order or the stock goods; 10 to 15 for mass production after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order. Please contact us for details.
Q4: How about the payment terms?
A: We usually require T/T in advance. If the amount is more than 5000USD, we can negotiate about the payment term,like 70% deposit in advance 30% pay before delivery, etc.
Q5: How about the certificates?
A:ISO9001,CE, TUV, UL, ROHS, CQC, REACH etc.
Q6: How about the sample?
A: Free samples. You need to pay for Currier cost. Please contact us for details.
Q7: What are services available after-sale?
A: Free replacement within three-month, free maintenance within six-year, life-long maintenance.
