| Brand Name: | VIIP |
| Model Number: | VIP4-1A-03(10329) |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | 33*33*18 |
| Payment Terms: | T/T, Western Union |
| Place of Origin | China |
| Model Number | VIP4-1A-03(10329) |
| Input Impedance | 50Ω |
| Insertion Loss | 30-100dB |
| Line To Line | 1760VDC |
| Nominal Center Frequency | 10KHZ~30MHZ |
| Certificate | ISO9001 CE ROHS cUL TUV |
| Operating Frequency | 50/60HZ |
| Temperature Range | 25 / 085 / 21 |
Single-Phase EMI Power Line Filters Features and Benefits:
More than two levels of fitering. 10 KHz一30 MHz broadbandhigh efficiencyfiltering,especally enhance the low- frequency filteringeffect between 10 KHz150 KHz.
Designed secialy for the tansmssion of military equipment through CE102 inGJB151A/ 152A
Work frequency. rated voltage to meet different requirements, rapid customizationdesign.
Designed for Common Mode Emissions or Susceptibility Application
Specifications for Single Phase EMI Power Line Filters:
| features for single phase emi filters |
| 1. Rated current: 0.5A-300A |
| 2.Various terminals: wire, solder lug, stud, terminal block ,etc |
| 3.Optional medical versions(H type) |
| 4.Custom specific versions are available on request |
| General purpose AC filters with good attenuation frequency range 150KHz-30MHz |
| Compact structure, high performance-cost ratio, easy to install,safe and reliable |
| VIP4 -1A and VIP4 -1B series are one - stage commonmode filters with almost the same filtering fleet, only slight differen different current |
| High voltage versions above 380VAC are also available |
| features for single phase emi filters |
| 1. Rated current: 0.5A-300A |
| 2.Various terminals: wire, solder lug, stud, terminal block ,etc |
| 3.Optional medical versions(H type) |
| 4.Custom specific versions are available on request |
| General purpose AC filters with good attenuation frequency range 150KHz-30MHz |
| Compact structure, high performance-cost ratio, easy to install,safe and reliable |
| VIP4 -1A and VIP4 -1B series are one - stage commonmode filters with almost the same filtering fleet, only slight differen different current |
| High voltage versions above 380VAC are also available |
Single Phase EMI Power Line Filters tabulates
| Part No. | Rated Current [A] | 250VAC/50Hz @ 20C Leakage Current [mA] |
Physical Dimensions | Electrical Schematics | Terminals | Weight [g] | ||
| screw | terminal block | wires | ||||||
| VIP1-1A-01 | 1A | <0.5mA | Fig 1 | Fig 1 | - - - | - - - | 0 | 65 |
| VIP1-1A-03 | 3A | <0.5mA | Fig 1 | Fig 1 | - - - | - - - | 0 | 65 |
| VIP1-1A-06 | 6A | <0.5mA | Fig 1 | Fig 1 | - - - | - - - | 0 | 65 |
| VIP1-1A-10 | 10A | <0.5mA | Fig 2 | Fig 1 | - - - | 0 | - - - | 75 |
| VIP4-1B-06 | 6A | <1.0mA | Fig 3/Fig4 | Fig 2 | M4 | 0 | - - - | 140 |
| VIP4-1B-10 | 10A | <1.0mA | Fig 3/Fig4 | Fig 2 | M4 | 0 | - - - | 170 |
| VIP4-1B-20 | 20A | <1.0mA | Fig 3/Fig4 | Fig 2 | M4 | 0 | - - - | 170 |
| VIP4-1B-30 | 30A | <1.0mA | Fig 5 | Fig 2 | M6 | - - - | - - - | 320 |
| VIP4-1B-50 | SOA | <2.0mA | Fig 5 | Fig 2 | M6 | - - - | - - - | 600 |
| VIP4-1B-100 | 100A | <2.0mA | Fig 5 | Fig 2 | M8 | - - - | - - - | 1380 |
| VIP4-1B-150 | 150A | <2.0mA | Fig 5 | Fig 2 | M10 | - - - | - - - | 1900 |
| VIP4-1B-200 | 200A | <2.0mA | Fig 5 | Fig 2 | M10 | - - - | - - - | 1900 |
FAQ:
Q1: Do you offer customized product ?
A: Yes, we can develop a new mold at you need if you can provide us with the samples or drawings and specification.
Q2: Are you a factory?
A: Yes, we are an ISO9001 manufacturer, an integration of EMI filter R&D, production and sales since 2009.
Q3: How long is the delivery time?
A: We ensure the fast delivery. Generally, it will take 2-5 days for small order or the stock goods; 10 to 15 for mass production after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order. Please contact us for details.
Q4: How about the payment terms?
A: We usually require T/T in advance. If the amount is more than 5000USD, we can negotiate about the payment term,like 70% deposit in advance 30% pay before delivery, etc.
Q5: How about the certificates?
A:ISO9001,CE, TUV, UL, ROHS, CQC, REACH etc.
Q6: How about the sample?
A: Free samples. You need to pay for Currier cost. Please contact us for details.
Q7: What are services available after-sale?
A: Free replacement within three-month, free maintenance within six-year, life-long maintenance.
|
