Flat Ferrite Core

Nizn Flat Snap On Ferrite Beads Magnetic Ring For Wireless Charging

All Category

Flat Ferrite Core

Miss. Vicky Lee

vip6@szviip.com

19925448748

Contact Now

Nizn Flat Snap On Ferrite Beads Magnetic Ring For Wireless Charging

Brand Name:	VIIP
Model Number:	V18016FS
MOQ:	Negotiable
Price:	Negotiable
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

Rohs Reach

Type:

Flat Snap-on

Composite:

Ferrite Magnet

Application:

Cables

Model:

V18016FS

Original Of Country:

China

Certificate:

Rohs Reach

Supply Ability:

5k For one week

Highlight:

Nizn Snap On Ferrite Beads

Soft Snap On Ferrite Beads

Wireless Charging Flat Ferrite Core

Product Description

Nizn Flat Snap On Ferrite Beads Magnetic Ring For Wireless Charging

Quick Detail:

Place of Origin:Guangdong, China
Brand Name:VIIP
Model Number:V18016FS
Type:Soft
Composite:Ferrite Magnet
Shape:Cylindrical
Application:Industrial Magnet
Tolerance:±1%
Delivery Time:within 7 days

Description

RFI EMI Noise Suppressor Cable Clip:EMI RFI Noise Filter Clip;Ferrite core with plastic cover; Helps to reduce EMI on AC power lines.

Ferrite Cores:Reduce electro-magnetic interference and improve signal integrity; Easy to install, just clip it on and you will get clearer signal and faster data transmission.

Nize ferrite ,it can improve the electromagnetic field around the solendoid ,thus avoiding outside interference.

Easy to install and convenient to use .The cylinder can be dismountable ,and the port has the elastic clip fastener.

Specifications:

Initial Permeability	850	Relative Loss Factor	16(0.1MHz)
Relative Temperature Coefficient	5~10	Saturation Magnetic Flux Density	350(1600A/m)
Remanence	200	Coercivity	20
Curie Temperature	>110	Electrical Resistivity	10 to the fifth power
Applied Frequency Range	1-1000	Density	4.7

Nizn Flat Snap On Ferrite Beads Magnetic Ring For Wireless Charging 0

No.	Specifications	Dimensions:mm					Impedance(Ω)min
No.	Specifications	ΦA	B	ΦC	D	E	25MHz	100MHz
1	V18014FS	36±1	9.4±0.8	28±1	14.8±1	2±0.4	45	110
2	V18015FS	37.9±1	12.5±0.8	28±1	18±1	2±0.4	55	110
3	V18016FS	54.4±1	13±0.8	44±1	18.4±1	2±0.4	55	125

Nizn Flat Snap On Ferrite Beads Magnetic Ring For Wireless Charging 1

Nizn Flat Snap On Ferrite Beads Magnetic Ring For Wireless Charging 3

Our Advantages

(1) Sales Network
Products are exported to Europe, the United States, South Korea, Southeast Asia and other countries and regions.

(2) Hardware Equipment
The company has fully automatic magnetic material detection equipment and production lines, and has an anti-interference magnetic core production base.

(3) Integrated Technical Service
Our company is an electromagnetic compatibility company integrating R&D, production and sales of anti-interference (EMC) electronic components and EMC testing services.

(4) Excellent Corporate Culture
The company organizes and implements quality management in strict accordance with standards, follows eight principles, and continuously improves work, with all employees as the first task to meet customer requirements
