Switching Power Supply 3 Phase Ac Line Filter , 6-200A Power Line Noise Filter

Brand Name:	VIIP WeiAiPu
Model Number:	VIP3-32B-03
MOQ:	1 PCS
Price:	Negotiable
Packaging Details:	333318
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE TUV UL CQC

Rated Voltage:

110/250VAC

Rated Current:

Nominal Center Frequency:

50/60Hz

1 PCS

Operating Frequency:

50/60HZ

Line To Line:

1450VDC

Input Impedance:

500VDC/100MOHM MIN

Frequency Range:

150 KHz To 30 GHz

Storage Temperature:

-40℃~+85℃

Item:

EMI Filter

Nominal Center Frequency:

50/60Hz,10KHZ~30MHZ,50/60Hz(MHz)

Dimensions:

Varies Depending On Model

Port:

Shenzhen

Port:

Shenzhen

Termination Style:

Solder Pins

Rated Current:

Different

Weight:

290g-1000g

Insulation Resistance:

≥100MΩ

Rohs Compliant:

Rohs Compliant:

Humidity:

≤95%RH

Humidity:

≤95%RH

Supply Ability:

2000 pcs within 10-15 days

Highlight:

200A 3 Phase Ac Line Filter

TUV Power Line Noise Filter

6A Power Line Noise Filter

Product Description

3 Phase Ac Filter 6-200A Power Line Niose Filter Switching Power Supply

VIP3-32A-03(B032W0765) Rev 4.0.pdf

Specification:

Item	3 Phase EMI Filter
Model	3 Phase EMI Filter - VIP3 Series
Transfer Function	Low Pass
Package Type	Surface Mount
Nominal working Frequency	150K-30MHZ
Insertion Loss	60~90dB
Input Impedance	50Ω
Rated Voltage	380V/440V
Current	3A
Working Temperature	40°C
Temperature	25 / 085 / 21
Operating Frequency	50/60HZ
Line to Line	2250VDC
Line to Ground	2700VDC
	110VAC/60HZ 1.4mA
MOQ	5pcs
Port	Shenzhen
Leading Time	3~15

Specifications:

Part No.	Rated Current [A]	250VAC/50Hz@20C Leakage Current [mA]	Physical Dimensions	Electrical Schematics	Termial	Weight [g]
VIP3-32B-10	10A	<4 OmA	Fig 2	Fig1	M4	1400
VIP3-32B-20	20A	<4 OmA	Fig 2	Fig1	M4	1400
VIP3-32B-50	50A	<60mA	Fig 2	Fig 1	M6	1600
VIP3-32B-100	100A	<60mA	Fig 2	Fig1	MS	3700
VIP3-32B-150	150A	<60mA	Fig 2	Fig1	M10	7000
VIP3-32B-200	200A	<60mA	Fig 2	Fig1	M10	7000
VIP3-32C-06	6A	<4 OmA	Fig 2	Fig 2	M4	650
VIP3-32C-10	10A	<4 OmA	Fig1	Fig 2	M4	650
VIP3-32C-20	20A	<10 OmA	Fig1	Fig 2	M4	1400
VIP3-32C-50	50A	<15 OmA	Fig 2	Fig 2	M6	3200

Physical Dimensions

Switching Power Supply 3 Phase Ac Line Filter , 6-200A Power Line Noise Filter 0

Electrical Schematic

Switching Power Supply 3 Phase Ac Line Filter , 6-200A Power Line Noise Filter 1

Insertion loss table(In 50ohm system according to IEC/CISPR No.17)

Switching Power Supply 3 Phase Ac Line Filter , 6-200A Power Line Noise Filter 2

Applications:

Widely used all kinds of electrical unit with ⛛ connection style,such as print machine ,packing machine ,textile equipment ,industry air conditioner ,UPS ,medical equipment .etc

Our Company

We have UL; cUL; TUV; CQC; CE; ROHS; ISO9001:2015; REACH certification to ensure the product quality

We have the relevant professional experimental equipment, so we can provide a free diagnostic conducting test for you.

Free EMC rectification technical support and provide free test sample

We have a professional R&D team
