Name: General Purpose Single Phase EMI Power Line Filters High Performance
Brand: Shenzhen VIIP Electronics Co., Ltd.
SKU: VIP4-1A-03
Price: 6.00 USD
Availability: InStock

Brand Name:	VIIP WeiAiPu
Model Number:	VIP4-1A-03
MOQ:	1 PCS
Price:	Negotiable
Packaging Details:	333318
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE TUV UL CQC

Rated Current:

Type:

EMC Filter

Transfer Function:

AC EMI Filter

Nominal Center Frequency:

150KHZ~30MHZ

Certification:

CE ROHS

Application:

Medical Equipments

Input Impedance:

500VDC/100MOHM MIN

Frequency Range:

150 KHz To 30 GHz

Storage Temperature:

-40℃~+85℃

Item:

EMI Filter

Operating Frequency:

50/60HZ

Nominal Center Frequency:

50/60Hz,10KHZ~30MHZ,50/60Hz(MHz)

Dimensions:

Varies Depending On Model

Port:

Shenzhen

Termination Style:

Solder Pins

Termination Style:

Solder Pins

Rated Current:

Different

Rated Current:

Different

Weight:

290g-1000g

Insulation Resistance:

≥100MΩ

Rohs Compliant:

Yes

Humidity:

≤95%RH

Supply Ability:

2000 pcs within 10-15 days

Highlight:

30MHZ EMI Power Line Filters

150KHZ EMI Power Line Filters

Single Phase EMI Filter CE

Product Description

High Performance General Purpose Single-Phase EMI Power Line Filters

VIP4-1A-03(B041W0638) Rev 4.0.pdf

High Performance General Purpose Single-Phase EMI Power Line Filters Quick Detail:

Place of Origin	China
Model Number	VIP4-1A-03
Input Impedance	50Ω
Insertion Loss	30-100dB
Line To Line	1760VDC
Nominal Center Frequency	10KHZ~30MHZ
Certificate	ISO9001 CE ROHS TUV
Operating Frequency	50/60HZ
Temperature Range	25 / 085 / 21

Features and Benefits for AC single phase emi filter:

150 KHz一30 MHz broadbandhigh efficiencyfiltering,especally enhance the low- frequency filteringeffect between 10 KHz150 KHz.

Designed secialy for the tansmssion of military equipment through CE102 inGJB151A/ 152A

Specifications For AC single phase emi filter:

General Purpose Single Phase EMI Power Line Filters High Performance 0

General Purpose Single Phase EMI Power Line Filters High Performance 1

High Performance General Purpose Single-Phase EMI Power Line Filters tabulates

Part No.	Rated Current [A]	250VAC/50Hz @ 20C Leakage Current [mA]	Physical Dimensions	Electrical Schematics	Terminals			Weight [g]
Part No.	Rated Current [A]	250VAC/50Hz @ 20C Leakage Current [mA]	Physical Dimensions	Electrical Schematics	screw	terminal block	wires	Weight [g]
VIP1-1A-01	1A	<0.5mA	Fig 1	Fig 1	- - -	- - -	0	65
VIP1-1A-03	3A	<0.5mA	Fig 1	Fig 1	- - -	- - -	0	65
VIP1-1A-06	6A	<0.5mA	Fig 1	Fig 1	- - -	- - -	0	65
VIP1-1A-10	10A	<0.5mA	Fig 2	Fig 1	- - -	0	- - -	75
VIP4-1B-06	6A	<1.0mA	Fig 3/Fig4	Fig 2	M4	0	- - -	140
VIP4-1B-10	10A	<1.0mA	Fig 3/Fig4	Fig 2	M4	0	- - -	170
VIP4-1B-20	20A	<1.0mA	Fig 3/Fig4	Fig 2	M4	0	- - -	170
VIP4-1B-30	30A	<1.0mA	Fig 5	Fig 2	M6	- - -	- - -	320
VIP4-1B-50	SOA	<2.0mA	Fig 5	Fig 2	M6	- - -	- - -	600
VIP4-1B-100	100A	<2.0mA	Fig 5	Fig 2	M8	- - -	- - -	1380
VIP4-1B-150	150A	<2.0mA	Fig 5	Fig 2	M10	- - -	- - -	1900
VIP4-1B-200	200A	<2.0mA	Fig 5	Fig 2	M10	- - -	- - -	1900
