CE 3 Phase AC Line EMI Filter , Elevator Inverter EMI Filter

Brand Name:	VIIP WeiAiPu
Model Number:	VIP3-31A-100
MOQ:	1 PCS
Price:	Negotiable
Packaging Details:	333318
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE TUV UL CQC

Product Name:

AC 3 PHASE EMI FILTERS

Rated Voltage:

110/250VAC

Rated Current:

5 PCS

Type:

EMC Filter

Application:

Electronic Equipments, Laser Equipment

Input Impedance:

500VDC/100MOHM MIN

Frequency Range:

150 KHz To 30 GHz

Storage Temperature:

-40℃~+85℃

Item:

EMI Filter

Operating Frequency:

50/60HZ

Nominal Center Frequency:

50/60Hz,10KHZ~30MHZ,50/60Hz(MHz)

Dimensions:

Varies Depending On Model

Port:

Shenzhen

Termination Style:

Solder Pins

Rated Current:

Different

Weight:

290g-1000g

Insulation Resistance:

≥100MΩ

Rohs Compliant:

Humidity:

≤95%RH

Supply Ability:

2000 pcs within 10-15 days

Highlight:

CE AC Line EMI Filter

3 Phase AC Line EMI Filter

250VAC Inverter EMI Filter

Product Description

3 Phase Ac Line Emi Filter Inverter EMI Filter / Elevator Inverter Rfi Filter

VIP3-31A-80(B031S0899) Rev 4.0.pdf

Description:

1, Rated currents from 0.5 to 2000A

2, High attenuation performance up to 30 MHz

3, Voltage rating 440VAC for worldwide acceptance

4, Approvals: CE, ROHS

5, 520V AC ,690V AC can be optional

Specification:

Item	VIIP 3-phase 3-line EMI filter
Part Number	VIP3-31A-100
Rated voltage	250/440VAC,50/60Hz
Operating frequency	DC to 60Hz
Rated currents	3~200A@40°C
Hipot Rating	L-L 2250VDC
	L-G 2700VDC
Climatic category	-25°C~+85°C(25/85/21)
Design corresponding to	UL1283, CSA C22.2 No.8,
	IEC/EN 60939,
	CQC GB 15288/GB 15287-2008
Flammability	UL 94V-0

Specifications:

Part No.

Rated Current [A]

250VAC/50Hz @ 20C
Leakage Current [mA]

Physical Dimensions

Electrical Schematics

Terminals

Weight [g]

VIP3-31A-06

<2.0mA

Fig 1

380

VIP3-31A-10

10A

<2.0mA

Fig 1

510

VIP3-31A-20

20A

<2.0mA

Fig 1

600

VIP3-31A-30

30A

<2.0mA

Fig 1

640

VIP3-31A-40

40A

<2.0mA

Fig 1

640

VIP3-31A-50

50A

<3.0mA

Fig 2

Fig 1

1000

VIP3-31A-80

80A

<7.0mA

Fig 2

Fig 1

3000

VIP3-31A-100

100A

<7.0mA

Fig 2

Fig 1

3000

VIP3-31A-150

150A

<7.0mA

Fig 2

Fig 1

M10

3200

VIP3-31A-200

200A

<7.0mA

Fig 2

Fig 1

M10

3200

Electrical schematic:

CE 3 Phase AC Line EMI Filter , Elevator Inverter EMI Filter 1

Mechanical Dimension(Unit: mm)

Applications:

such as print machine

packing machine

textile equipment

industry air conditioner

UPS

medical equipment

Laser equipment

FAQ

About VIIP
Q:Are you manafacturer or trading company?
Shenzhen VIIP is a manafacturer forEMI/EMC Products located in Shenzhen Guangdong China.

About Products
Q:What certification do you have for your products?
We have got CE ROHS FCC and so on.
Q:What is your MOQ?
It depends on different items,we have low MOQ request ,because we have a big warehouse for stock orders.
Q:What shipping ways do you support for delivery?
We support air, sea and railway shipment.

About Sample Order
Q: Can I have a sample order for your products?
A: Yes, we offer product samples, including mixed samples.

About Service

Q: Which payments are acceptable?
A:We accept T/T, Paypal, Western Union ect.
Q: Can I visit your company and factory in China?
A: Sure. We are happy to receive you in Shenzhen, China and show you around our workplaces.
