50A 3 Phase EMI Filter 60dB-90dB Three Phase Line Filter

50A 3 Phase EMI Filter 60dB-90dB Three Phase Line Filter
50A 3 Phase EMI Filter 60dB-90dB Three Phase Line Filter
50A 3 Phase EMI Filter 60dB-90dB Three Phase Line Filter 50A 3 Phase EMI Filter 60dB-90dB Three Phase Line Filter

Large Image :  50A 3 Phase EMI Filter 60dB-90dB Three Phase Line Filter

Product Details:
Place of Origin: China
Brand Name: VIIP
Certification: CE TUV UL ROHS REACH
Model Number: VIP3-31A-50
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 33*33*18
Payment Terms: T/T, Western Union
Supply Ability: 2000 pcs within 10-15 days

50A 3 Phase EMI Filter 60dB-90dB Three Phase Line Filter

Description
Product Name: AC 3 PHASE EMI FILTERS Rated Current: 50A
Type: EMC Filter Rated Voltage: 110/250VAC
Certification: CE ROHS Insertion Loss: 60dB-90dB
High Light:

50A 3 Phase EMI Filter 60dB

,

90dB Three Phase Line Filters

,

3 Phase EMI Filter 60dB

10A 3 Line 3 Phase EMI Filter For Office And High Power Office Equipment



Description:



1, Rated currents from 0.5 to 2000A

2, High attenuation performance up to 30 MHz

3, Voltage rating 440VAC for worldwide acceptance

4, Approvals: CE, ROHS

5, 520V AC ,690V AC can be optional

Specification:



Item 3 Phase EMI Filter
Model 3 Phase EMI Filter - VIP3 Series
Original of country China
Package Type Surface Mount
Nominal working Frequency 150K-30MHZ
Insertion Loss 60~90dB
Input Impedance 50Ω
Rated Voltage 380V/440V
Current 50A
Working Temperature 40°C
Climatic category 25 / 085 / 21
Operating Frequency 50/60HZ
Line to Line 2250VDC
Line to Ground 2700VDC
  110VAC/60HZ 1.4mA
MOQ 5pcs
Port  Shenzhen
Leading Time 3~15 days for Low Pass EMI Filter

















Specifications:





50A 3 Phase EMI Filter 60dB-90dB Three Phase Line Filter 0

50A 3 Phase EMI Filter 60dB-90dB Three Phase Line Filter 1







Applications:



 such as print machine

packing machine

textile equipment

industry air conditioner

UPS

medical equipment
