Item | Power line EMI Filter |
Model | VIP4-3A-50 |
port | Shenzhen |
Package Type | Surface Mount |
Nominal Center Frequency | 10Khz-30MHZ |
Insertion Loss | 60~90dB |
Input Impedance | 50Ω |
Rated Voltage | 110V/250V |
Rated Current | 50A |
Environmental Temperature | 40°C |
Temperature Range | -25℃~+85℃ |
Operating Frequency | 50/60HZ |
Line to Line | 1760VDC |
Line to Ground | 2000VDC |
Samples | available |
MOQ | 1 PCS |
Price | Negotiated |
Lead Time | 3~20 days |
EMC EMI FILTER Features:
--high performance with common and differential mode attenuation performance
-- Various terminal options allow you to select
-- There are a variety of parts and combinations to meet different customer's EMC tests.
-- 380VAC are also available
EMC EMI FILTER Applications:
1. Electrical and electronic equipment
2. Single phase servo motor
3. Datacom equipment
4. inverters and converters
5. Charging post
6.Led equipment
Tabulates for single phase emi filter:
Part No. | Rated Current [A] | 250VAC/50Hz @ 20C Leakage Current [mA] |
Physical Dimensions | Electrical Schematics | Terminals | Weight [g] | ||
screw | terminal block | wires | ||||||
VIP4-3A-01 | 1A | <1.5mA | Fig 1 | Fig 1 | - - - | - - - | 0 | 95 |
VIP4-3A-03 | 3A | <1.5mA | Fig 2 | Fig 1 | - - - | 0 | - - - | 145 |
VIP4-3A-06 | 6A | <1.5mA | Fig 3 | Fig 1 | M4 | - - - | - - - | 450 |
VIP4-3A-10 | 10A | <2.5mA | Fig 3 | Fig 1 | M4 | - - - | - - - | 550 |
VIP4-3A-20 | 20A | <2.5mA | Fig 3 | Fig 1 | M6 | - - - | - - - | 550 |
VIP4-3A-50 | 50A | <2.5mA | Fig 3 | Fig 1 | M6 | - - - | - - - | 3300 |
VIP4-3A-100 | 100A | <4.0mA | Fig 3 | Fig 1 | M8 | - - - | - - - | 3400 |
VIP4-3A-150 | 150A | <4.0mA | Fig 3 | Fig 1 | M10 | - - - | - - - | 3600 |
Electrical schematic:
Mechanical Dimension(Unit: mm)
FAQ:
Q: What are the main products of your company?
A: IEC inlet socket EMI filter, single-phase filter, house appliance noise filter, Medical equipment filter, inver/converter EMC filter and ther emi/emc ferrite core etc.
Q: How is the quality of your product?
A: All our products have pass UL, TUV, CE, ROHS, ISO9001 approval. which ensures the quality of the product.
Q: What are services available for pre-batch orders?
A: Free samples and EMC technical rectification services are supplied before-sale
Q: What are services available after-sale?
A: Free replacement within three-month, free maintenance within six-year, life-long maintenance.
Q: Are OEM and ODM services available?
A: Yes, we can accept OEM or ODM customers only if you meet our MOQ request.
