Flat Ferrite Core
>
Electrical Resistivity EMI Suppression Nizn Flat Ferrite Core SCFS TYPE Industrial Magnet

Electrical Resistivity EMI Suppression Nizn Flat Ferrite Core SCFS TYPE Industrial Magnet

Brand Name: VIIP
Model Number: V18016FS
MOQ: Negotiable
Price: Negotiable
Payment Terms: T/T, Western Union
Detail Information
Place of Origin:
china
Certification:
Rohs Reach
Type:
Flat Snap-on
Composite:
Ferrite Magnet
Application:
Cables
Model:
V18016FS
Original Of Country:
China
Certificate:
Rohs Reach
Supply Ability:
5k For one week
Highlight:

EMI Suppression Flat Ferrite Core

,

Industrial Magnet Flat Ferrite Core

,

Electrical Resistivity Flat Ferrite Core

Product Description

Electrical Resistivity EMI Suppression Nizn Flat Ferrite Core SCFS TYPE Industrial Magnet



Quick Detail:



  • Place of Origin:Guangdong, China
  • Brand Name:VIIP
  • Model Number:V18016FS
  • Type:Soft
  • Composite:Ferrite Magnet
  • Shape:Cylindrical
  • Application:Industrial Magnet
  • Tolerance:±1%
  • Delivery Time:within 7 days

Description



RFI EMI Noise Suppressor Cable Clip:EMI RFI Noise Filter Clip;Ferrite core with plastic cover; Helps to reduce EMI on AC power lines.



Ferrite Cores:Reduce electro-magnetic interference and improve signal integrity; Easy to install, just clip it on and you will get clearer signal and faster data transmission.

 Nize ferrite ,it can improve the electromagnetic field around the solendoid ,thus avoiding outside interference.

 Easy to install and convenient to use .The cylinder can be dismountable ,and the port has the elastic clip fastener.



Specifications:

Initial Permeability
850
Relative Loss Factor
16(0.1MHz)
Relative Temperature Coefficient
5~10
Saturation Magnetic Flux Density
350(1600A/m)
Remanence
200
Coercivity
20
Curie Temperature
>110
Electrical Resistivity
10 to the fifth power
Applied Frequency Range
1-1000
Density
4.7

Electrical Resistivity EMI Suppression Nizn Flat Ferrite Core SCFS TYPE Industrial Magnet 0

No. Specifications Dimensions:mm Impedance(Ω)min
ΦA B ΦC D E 25MHz 100MHz
1 V18014FS 36±1 9.4±0.8 28±1 14.8±1 2±0.4 45 110
2 V18015FS 37.9±1 12.5±0.8 28±1 18±1 2±0.4 55 110
3 V18016FS 54.4±1 13±0.8 44±1 18.4±1 2±0.4 55 125

Electrical Resistivity EMI Suppression Nizn Flat Ferrite Core SCFS TYPE Industrial Magnet 1Electrical Resistivity EMI Suppression Nizn Flat Ferrite Core SCFS TYPE Industrial Magnet 2







Electrical Resistivity EMI Suppression Nizn Flat Ferrite Core SCFS TYPE Industrial Magnet 3



What can you do with a ferrite core?



Ferrite cores are versatile components used in a wide range of electronic and electrical applications. Here are several common uses for ferrite cores:

EMI Suppression: One of the primary uses of ferrite cores is to suppress electromagnetic interference (EMI) in electronic circuits, cables, and wiring. They are often placed around cables or wires to absorb and attenuate high-frequency noise, reducing the impact of EMI on electronic devices and systems.

Inductors and Transformers: Ferrite cores are employed in the construction of inductors and transformers. When wound with wire, the ferrite core helps to concentrate and guide the magnetic field, enhancing the inductance and performance of these components.

Noise Filters: Ferrite cores are used in noise suppression and filtering applications, where they help to eliminate unwanted electromagnetic noise from power lines, signal lines, and data cables. They are commonly integrated into noise suppression devices and filters to improve the signal quality and reduce interference.

Power Supplies: Ferrite cores play a crucial role in the design of power supplies, where they are used in the construction of inductors and transformers to manage power conversion and distribution. They help to regulate and control the flow of electrical energy within power supply circuits.
