Name: 240V Mains EMI Filter For AC Power Supply
Brand: Shenzhen VIIP Electronics Co., Ltd.
SKU: VIP4-1A-10
Price: 14.05 USD
Availability: InStock

Brand Name:	VIIP
Model Number:	VIP4-1A-10
MOQ:	Negotiable
Price:	Negotiable
Packaging Details:	333318
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE TUV UL ROHS REACH

Rated Current:

10A

Type:

AC EMI Filter

Rated Voltage:

110/250VAC

Nominal Center Frequency:

150KHZ~30MHZ

Application:

Electronic Equipments

Line To Line:

1760VDC

Supply Ability:

2000 pcs within 10-15 days

Highlight:

EMI Filter For AC Power Supply

240V Mains EMI Filter

240V EMI Filter For AC Power Supply

Product Description

Industrial AC emi Filter EMC RFI 240V AC Mains Filter power supply

Quick Detail:

Item	Power line EMI Filter
Model	VIP4-1A-10
case	metal
Package Type	Surface Mount
Frequency Range	150K-30MHZ
MOQ	1PCS
Input Impedance	50Ω
Rated Voltage	110V/250V
Rated Current	10A
Line to Ground	2000VAC

General purpose single phase AC power line filters ,easy to install ,available for

--Electrical and electronic equipment

-- Medical equipment

-- Building automation

-- Office automation and datacom equipment

Specifications:

Part No.	Rated Current [A]	250VAC/50Hz @ 20C Leakage Current [mA]	Physical Dimensions	Electrical Schematics	Terminals			Weight [g]
Part No.	Rated Current [A]	250VAC/50Hz @ 20C Leakage Current [mA]	Physical Dimensions	Electrical Schematics	screw	terminal block	wires	Weight [g]
VIP4-1A-01	1A	<0.5mA	Fig 1	Fig 1	- - -	- - -	0	65
VIP4-1A-03	3A	<0.5mA	Fig 1	Fig 1	- - -	- - -	0	65
VIP4-1A-06	6A	<0.5mA	Fig 1	Fig 1	- - -	- - -	0	65
VIP4-1A-10	10A	<0.5mA	Fig 2	Fig 1	- - -	0	- - -	75
VIP4-1B-06	6A	<1.0mA	Fig 3/Fig4	Fig 2	M4	0	- - -	140
VIP4-1B-10	10A	<1.0mA	Fig 3/Fig4	Fig 2	M4	0	- - -	170
VIP4-1B-20	20A	<1.0mA	Fig 3/Fig4	Fig 2	M4	0	- - -	170
VIP4-1B-30	30A	<1.0mA	Fig 5	Fig 2	M6	- - -	- - -	320
VIP4-1B-50	50A	<2.0mA	Fig 5	Fig 2	M6	- - -	- - -	600
VIP4-1B-100	100A	<2.0mA	Fig 5	Fig 2	M8	- - -	- - -	1380
VIP4-1B-150	150A	<2.0mA	Fig 5	Fig 2	M10	- - -	- - -	1900
VIP4-1B-200	200A	<2.0mA	Fig 5	Fig 2	M10	- - -	- - -	1900

Electrical schematic:

240V Mains EMI Filter For AC Power Supply 0

Mechanical Dimension(Unit: mm)

Sample

Sample Fee: Negotiate

Sample Time: 2~5 days

Payment

---Payment terms: Western Union, T/T

---Please remember to leave the correct contact information for delivery.
